| Spec/Model |
FH-120-WI-PP |
FH-150-WI-PP |
FH-180-WI-PP |
FH-200-WI-PP |
FH-250-WI-PP |
External
Dimensions
W x D x H |
1200 x 930 x 2320 mm
47.3x 36.6 x 91.3” |
1500 x 930 x 2320 mm
59.0 x 36.6 x 91.3” |
1800 x 930 x 2320 mm
70.8 x 36.6 x 91.3” |
2000 x 930 x 2320 mm
78.7 x 36.6 x 91.3” |
2500 x 930 x 2320 mm
98.4 x 36.6 x 91.3” |
Workspace
(W x D x H) |
1000 x 650 x 1990 mm
39.4 x 25.6 x 78.3” |
1300 x 650 x 1990 mm
51.2 x 25.6 x 78.3” |
1600 x 650 x 1990 mm
63 x 25.6 x 78.3” |
1800 x 650 x 1990 mm
70.8 x 25.6 x 78.3” |
2300 x 650 x 1990 mm
90.5 x 25.6 x 78.3” |
Workspace
(W x D x H) |
1 X 12”/315MM |
1 X 12”/315MM |
1 X 12”/315MM |
2 X 12”/315MM |
2 X 12”/315MM |
| WE CAN CUSTOMIZE ANY SIZE – EVEN A SINGLE UNIT! CONTACT US FOR DETAILS |
Front Sash
Max Opening |
1800 mm / 70.8" |
1800 mm / 70.8" |
1800 mm / 70.8" |
1800 mm / 70.8" |
1800 mm / 70.8" |
Production /
test Standard |
CE |
| Air Velocity |
0.5±0.1 m/s, 100±20 fpm |
| Hood Material |
Polypropylene |
| Control System |
The standard control system is a 7” color display with on/off controls |
| Optional |
Water tap/ gas tap / vacuum tap/ pp sink / triplex glass / explosion-proof light |
| Power Supply |
110/220 V, 50/60 Hz.
Includes a single-phase power supply. A three-phase power supply can be special ordered. |
| Illumination |
800 lux LED lights |
