| External Dimensions W x D x H |
1200 x 800 x 2350mm
47.2 x 31.5 x 92.5” |
1500 x 800 x 2350mm
59 x 31.5 x 92.5” |
1800 x 800 x 2350mm
70.8 x 31.5 x 92.5” |
2000 x 800 x 2350mm
78.7 x 31.5 x 92.5” |
2200 x 800 x 2350mm
86.6 x 31.5 x 92.5” |
| Workspace (W x D x H) |
950 x 630 x 1145mm
37.4 x 24.8 x 45” |
1250 x 630 x 1145mm
49.2 x 24.8 x 45” |
1550 x 630 x 1145mm
61 x 24.8 x 45” |
1750 x 630 x 1145mm
68.9 x 24.8 x 45” |
1950 x 630 x 1145mm
76.8 x 24.8 x 45” |
| Exhaust Collar Dimensions |
1 x 10”/250MM |
1 x 10”/250MM |
1 x 10”/250MM |
1 x 12”/315MM |
1 x 12”/315MM |
| WE CAN CUSTOMIZE ANY SIZE – EVEN A SINGLE UNIT! CONTACT US FOR DETAILS |
| Front Sash Max Opening |
860 mm / 33.8" |
| Production / test Standard |
EN-14175 / ASHRAE 110-1995 |
| Air Velocity |
0.5±0.1 m/s, 100±20 fpm |
| Hood Material |
Metal epoxy-coated paint |
| Worktop |
The standard worktop is ceramic, other options are: HPL / polypropylene / Epoxy / Stainless steel |
| Control System |
The standard control system is A 7” color display with on/off controls |
| Optional |
Water tap / gas tap / vacuum tap / pp sink / triplex glass / explosion-proof light |
| Power Supply |
110/220 V, 50/60 Hz.
Includes a single-phase power supply. A three-phase power supply can be special ordered. |
| Illumination |
800 lux |
