| Spec/ Model |
BO-090-PP |
BO-120-PP |
BO-150-PP |
BO-180-PP |
| Outer Dimensions W x D x H |
915 x 800 x 1500 mm
36 x 31.5 x 59” |
1220 x 800 x 1500 mm
48 x 31.5 x 59” |
1525 x 800 x 1500 mm
60 x 31.5 x 59” |
1830 x 800 x 1500 mm
72 x 31.5 x 59” |
| Workspace (W x D x H) |
835 x 600 x 640 mm
32.8 x 23.6 x 25.2” |
1135 x 600 x 640 mm
44.7 x 23.6 x 25.2” |
1440 x 600 x 640 mm
57 x 23.6 x 25.2” |
1715 x 600 x 640 mm
67.5 x 23.6 x 25.2” |
| Front Sash Max Opening |
480 mm / 18.9" |
| Certifications |
CE / EN 12469 * |
| Downflow Velocity |
0.33 m/s, 66 fpm |
| Inflow velocity |
0.5 m/s, 100 fpm |
| Airflow pattern |
CLASS II, Type A2: 70% circulation, 30% exhaust |
| Cleanliness level |
Class 100/ISO 5 |
| Hood Material |
Welded white polypropylene structure. 304 stainless steel interior. Options for windowless sides or a 316 stainless steel structure |
| Adjustable Stand Height Range |
70/80/90 cm (27/31/36”) |
| Noise Level (Tested 20cm/8” from the worktable, 1.2m/48” above ground) Noise |
< 56dB |
< 60dB |
< 63dB |
< 63dB |
| Power Supply |
115 / 230 V, 50/60 Hz, Single phase |
| Illumination |
1000 LUX, Eco-friendly LED lighting |
| Filters |
ULPA H15 Efficiency 99.9995% @ 0.1 µm |
