| Spec/Model |
FH-120-WD |
FH-150-WD |
FH-180-WD |
FH-200-WD |
FH-250-WD |
| External Dimensions W x D x H |
1200 x 980 x 2370mm 47.3x 38.6 x 93.3” |
1500 x 980 x 2370mm 59 x 38.6 x 93.3” |
1800 x 980 x 2370mm 70.9 x 38.6 x 93.3” |
2000 x 980 x 2370mm 78.8 x 38.6 x 93.3” |
2500 x 980 x 2370mm 98.4 x 38.6 x 93.3” |
| Exhaust Collar Dimensions |
1 X 10”/250MM |
1 X 10”/250MM |
1 X 10”/250MM |
1 X 12”/315MM |
2 X 10”/250MM |
| WE CAN CUSTOMIZE ANY SIZE – EVEN A SINGLE UNIT! CONTACT US FOR DETAILS |
| Workspace (W x D x H) |
1000 x 630 x 1000mm 39.4 x 24.8 x 39.4” |
1300x630x1000mm 51.2×24.8×39.4” |
1600x630x1000mm 63×24.8×39.4” |
1800x630x1000mm 70.8×24.8×39.4” |
2300x630x1000mm 90.5×24.8×39.4” |
| Front Sash Max Opening |
720mm/28.3” |
720mm/28.3” |
720mm/28.3” |
720mm/28.3” |
720mm/28.3” |
Production /
test Standard |
CE |
| Air Velocity |
0.5±0.1 m/s, 100±20 fpm |
| Hood Material |
Polypropylene |
| Worktop Material |
The standard worktop is polypropylene , other options are: HPL / Ceramic / Epoxy / Stainless steel |
| Control System |
The standard control system is a 7” color display with on/off controls |
| Optional |
Water tap/ gas tap / vacuum tap / pp sink |
| Power Supply |
110/220 V, 50/60 Hz.
Includes a single-phase power supply. A three-phase power supply can be special ordered. |
| Illumination |
800 lux LED lights |
